Mirage 4 ES Black

Mini-Tower Gaming PC Case

MATCH YOUR STYLE

Available in black and white to suit any PC theme. Whether you prefer a sleek black build or a clean white setup, this case fits your style.

Vertical Airflow & Top 240mm Radiator

Enhanced airflow and a top-mounted 240mm radiator ensure your system stays cool under pressure.

5 PCIe Slots for Cooling and Compatibility

5-slot PCIe layout improves GPU compatibility and cooling, with reusable top two slots.

PSU Extra-Wide Space

Max. PSU Length ≤ 240mm
Enjoy 60mm extra space for a smoother build!

Generously Spacious Cable Management

Easily organize cables with ample space for a clean, efficient build and improved airflow.

1.2mm Vent Holes

The 1.2mm mesh on the right panel enhances airflow, delivering optimal cooling performance.

Tool-Free Panel

The front and left side panels use a fixing stud design, simplifying assembly and disassembly while reducing the risk of glass breakage.

Maximize Storage

Install 2 SSDs on the outer side of the bracket, 1 HDD on the inner side, and 1 SSD on the right side of the motherboard for efficient storage.

Storage Bracket Assembly Guide

Tools are required for installation and removal.
Follow the illustrated steps for proper setup.

Multi-Function Zone

Introducing Feature-Rich Multi-Functional Zone for Readily Accessable User-Computer Interaction.

Two Full-Size Magnetic Filters

CPU Air Cooling Compatibility

Max. CPU Cooler Height ≤ 155mm

Effortless Setup for Your Convenience

Pre-installed with 6 copper standoffs and included tool for easy installation and removal.

Cable Management Diagram

Experience Ultimate Cooling Solution

Compatibility

Specifications

Model Name

Mirage 4 ES Black

Model Number

OKICC-MG4ES-MATXB

EAN

4897121941482

Dimensions

347 x 275 x 355mm (DWH)

Form Factor

Mini Tower

Materials

Steel

Mainboard Support

Micro-ATX, ITX

Front Access & Controls

Power, LED Control Button, USB3.0 x 1, USB 2.0 x 1, Type-C 3.2 Gen 1 (5 Gbps)x 1, Headphone/Mic Combo Jack

Side Panel

Tempered Glass Side Panel

Drive Bays

Expansion Slots

3.5″

2.5″

Fan Support

Top

2 x 120mm

Bottom

2 x 120mm

Rear

1 x 120mm

Included Fan(s)

2 x 120 D12R ARGB Annxe reserve fans at bottom + 1 x 120 D12 ARGB Main fan in rear

Radiator Support

Top

240/120mm

Rear

120mm

Clearance

Max GPU Length

≤325mm

Max CPU Cooler Height

≤155mm

Max PSU Length

(Without cable)≤180mm

Miscellaneous

Dust Filter

Top / Bottom

Net Weight

4.41 Kg

Gross Weight

5.61 Kg

Special Features

270-degree panoramic design enhances aesthetics and openness, featuring a tool-free tempered glass panel for easy access and added protection.
Vertical airflow system supports up to 5 fans, optimizing bottom-to-top thermal management for superior cooling efficiency.
The right panel is equipped with a 1.2mm mesh, enhancing airflow for superior cooling performance.
Pre-installed 2 x 120mm D12R ARGB 3-Pin at the bottom, and 1 x 120mm D12 ARGB 3-Pin at the rear
5-slot PCIe layout improves GPU compatibility and improves cooling space.
Pre-locked copper standoffs for easy installation and removal.
Full-size magnetic dust filters on the top and bottom ensure clean airflow and easy maintenance.
Generous cable management space: 95mm on the right and 45mm on the left, ensuring a seamless and hassle-free building experience.
